TWIST J1900 POS

AURES

269.000 KD

Intel Bay Trail Celeron J1900 Processor - 4GB DDR4 "Upto 8GB" - SSD 128GB "Second Slot Available" - 13.3 inch Full HD LCD Ultra Slim & Edgeless Touch Panel with Multi-Touch projected Capacitive Technology - USB-C Port Available- FANLESS - Black Color

Warranty

1Year

TWIST

Adaptable, multi-view POS

DATASHEET TWIST

TWIST

VERSATILE AUTO-ROTATIVE POS SYSTEM WITH CONTEMPORARY GEOMETRIC DESIGN

Model	TWIST
Processors	Intel Bay Trail Celeron J1900	Intel Skylake i3-6100U	Intel Kaby Lake i5-7300U
Memory (RAM)	4GB DDR3L SODIMM up to 8GB	4GB DDR4 SODIMM up to 16GB	4GB DDR4 SODIMM up to 16GB
Graphic memory	Intel HD Graphics Core
SSD	2 slots ( SSD M.2, 1 x 128GB in standard)
LCD	13.3” - 1920 x 1080 full HD - LED back-lighting
Touch panel	Ultra flat (2.8 mm) and edgeless –multitouch projective capacitive technology
Brightness	300 cd/m2
Input-Output Ports
Serial	2 x serial ports - 1 power supply (5V)
USB ports	6 x USB 3.0 ports with 2 on the side 2 x USB-C (one for the motherboard and the processor + one available)
LAN	10/100/1000Base-T
2nd Screen	Supports HDMI, DVI, VGA and DisplayPort via USB-C
Audio	Integrated loudspeaker (1 x 2W)
Power supply	External + 19V 65W
Various
EMI	CE/FCC Class A
Security	LVD, external adaptor UL /c/us, CE, TUV, etc.
Operating temperature	0~40°
Front face	Dust and splash proof
Colour	black
Dimensions (L x D x H)	321.36 x 216.15 x 122.8 (in its vertical configuration)
Weight (net/gross)	3 kg / 4 kg
Positionning angle (auto-rotating base)	2 possible options (desk version (flat) or more vertical angle)
Compatible OS	Windows 7/10, Linux, Android	Windows 7/10, Linux	Windows 10, Linux
OPTIONS
MSR reader
Addimat and/or Dallas readers	Can be positioned on the right side of the POS system
Biometric reader	For finger prints
Barcode reader	External
Customer display	20 characters x 2 lines (TFT) - multilingual with chinese
2nd screen	External
WIFI	Internal, 802.11 ac and Bluetooth
